Single-Button Operation with Auto-Return

The Loading Systems swing lip leveller operates with a single button press — the platform rises, the lip extends onto the vehicle bed, and loading proceeds. When the "Auto-Return" button is pressed at completion, the leveller automatically returns to the stored position. No operator training required, minimal process interruption.

Closed Hydraulic System — Long Service Life

The fully closed hydraulic system operates at low pressure with a single chrome-hardened main cylinder with double sealing — resulting in minimal maintenance requirements and a long service life. Self-supporting frame construction eliminates structural pit requirements in many installations.

CE Marked — EN 1398:2009 Compliant

Every Loading Systems dock leveller carries CE marking and complies with all safety aspects of EN 1398:2009 — including safety stop control valves in hydraulic cylinders, emergency stop, and clearly marked moving parts. The European safety standard for dock levellers, supplied as standard.

What Is the Loading Systems Swing Lip Dock Leveller?

The Loading Systems swing lip dock leveller is a hydraulic dock leveller manufactured by Loading Systems BV — the European market leader in loading dock equipment since 1965, headquartered in Lelystad, Netherlands. Over 50 years of dock equipment engineering, refinement and field experience are embedded in the Loading Systems dock leveller range — not as historical footnotes, but as the accumulated knowledge that drives current product design decisions and distinguishes a Loading Systems leveller from a commodity product selected on price.

The swing lip leveller operates on a closed hydraulic system at low pressure, using a single chrome-hardened main cylinder with double sealing — a system designed for minimal maintenance and a long service life in the high-cycle, high-load conditions of an active loading dock. The single button activates the sequence: platform rises, swing lip extends onto the vehicle bed under gravity, loading proceeds. The Auto-Return button at completion returns the leveller to the stored position automatically.

Technical Specifications

SpecificationsValue
Lip TypeSwing lip
DriveHydraulic — closed system, single chrome-hardened cylinder
Standard Load60 kN (6 tonne) · Higher capacities available
Working RangeUp to +520mm rise / -470mm fall (model dependent)
DimensionsAvailable in range of standard widths and lengths
OperationSingle-button with Auto-Return function
FinishAny RAL colour · Hot-galvanised optio
Pit StyleOpen or closed pit — both supported
CertificationsCE Marked · EN 1398:2009 · Loading Systems proprietary coating

Industries Served

Where the Swing Lip Dock Leveller Here Is Used

Food Manufactuuring

Logistics & Warehousing

Supermarket & Retail

Downloads

Technical Documentation

Download the full product specification sheet, installation guide, and compliance certificates.

Get a Quote

Enquire About This Product

Our team will respond within one business day with pricing, lead times, and installation options.
