80mm Panels — Highest Insulation Class

80mm thick panels achieve insulation in the highest class for sectional overhead doors. The T80-ISO with ISO pack delivers a U-value 25% better than a standard T80 door, achieved through track insulators, top and bottom profiles and end caps in thermally non-conductive plastic that eliminate thermal bridges.

Thermally Broken — No Cold Bridging

The ISO package eliminates all thermal bridges between panel and frame — critical in cold storage dock applications where conventional sectional door frames conduct cold directly to the surrounding structure, causing condensation, ice and structural damage over time.

Investment That Pays Back

A sectional door remains closed more than 90% of the time. Upgrading from 40mm to 80mm panels with the ISO package pays back through energy savings, particularly in cold storage and refrigerated dock environments operating continuously. The performance gap between a well-insulated door and an under-specified door compounds over years.

The highest-performance sectional door

The HFIS80 is Hold Fast Industries’ premium 80mm thermally-broken insulated sectional overhead door — the highest-performance sectional door in the HFI range, engineered for temperature-controlled loading bays, cold storage docks, pharmaceutical facilities and high-performance industrial buildings where the thermal performance of every element of the building envelope matters.

Where the HFIS40 provides standard industrial insulation, the HFIS80 with the ISO thermal break package delivers a U-value of approximately 0.52 W/m²K — more than twice the thermal resistance of the standard 40mm door. This improvement is achieved through three mechanisms: doubled panel thickness (80mm vs 40mm PU foam core), plus a track insulator, thermally non-conductive PVC top and bottom profiles, and PVC end caps that eliminate the thermal bridges between the panel and the surrounding frame at every connection point.

Technical Specifications

SpecificationsValue
Panel Thickness80mm steel sandwich panels
U-ValueT80 standard: ~0.7 W/m²K · T80-ISO with ISO pack: ~0.52 W/m²K
ISO Package Track insulators + top/bottom profiles + end caps (thermally non-conductive)
Panel MaterialGalvanised stucco-finish steel exterior, galvanised or powder-coated interior
InsulationFire-resistant polyurethane foam — CFC free
SafetyFinger pinch protection (standard)
Hinge DurabilityOuter plate folded 4× on hinge side — 1.6mm effective thickness for long hinge life
FinishStandard stucco finish with horizontal grooves · RAL powder coat options
CertificationsCE Marked · EN 13241 · Corrosion resistance class II DIN 55928-8

Industries Served

Where the HFIS80 Here Is Used

cold storage

Food Manufactuuring

Pharmaceutical

Logistics & Warehousing

Downloads

Technical Documentation

Download the full product specification sheet, installation guide, and compliance certificates.

Product Datasheet

Filesize - 2MB

Get a Quote

Enquire About This Product

Our team will respond within one business day with pricing, lead times, and installation options.
